Download Documentation

SR3602-28 – TDS

SR3602-28 -- TDS

Request a Sample

Specifications

Test

Specification

Appearance

Viscous Clear Red / Brown Liquid

Viscosity

5,000 – 7,500 mPas @ 25°C

Non Volatiles

27 – 29%

Density

~1.05 g/mL @ 23°C

pH

9-10

Certifications & Registrations

ISO 9001:2015 is a globally recognized standard for quality management systems. It is a framework encompassing all aspects of business operations, from leadership and planning to support and performance evaluation. ISO 9001:2015 certified through DQS; BR#: 10016110 QM15.

Reach certification status

Ask us about our Reach certification status

Specifications

REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) compliance is for the manufacturers and importers of chemicals in the EU. Ask us if this chemical complies with regulations and is registered with the European Chemicals Agency (ECHA), which aims to ensure a high level of protection of human health and the environment against harmful substances..

SR3602-28 is an aqueous version of the 3602 series (NMP solvent) of aromatic polyamide-imide resins, enabling further dilutions with water.


Coatings produced from SR3602-28 provide:

  • Excellent thermal stability (polymer will typically withstand temperature excursions up to 240ºC)
  • High level of chemical resistance
  • Good abrasion resistance
  • FDA compliance
Ammonium Benzoate Uses and applications

SR3602-28 is typically used in the following applications:

  • Temperature resistant coatings
  • Binder for high temperature resistant fiber reinforced plastics
  • Bonding agent for high temperature applications up to 240°C
  • FDA compliant coatings
  • Dielectric materials for electronic circuit boards

The excellent chemical resistance of these polymers leads to applications in container coatings, “non-stick” cookware, electronics, and other areas. Coatings can be produced from SR3602-28 that meet requirements of FDA regulations 177.2450 and can therefore be used in the manufacture of cookware coatings.

Use de-mineralized or distilled water.

SR3602-28 is supplied as a solution; care must be taken to enable the solvent to be removed slowly to
avoid blistering of the film. During curing, the temperature of the object should be increased slowly up to the final cure temperature to avoid blistering of the coating due to final release of solvent. Final cure temperature of >220°C is required.

It is advised not to mix used material with unused product for storage, although topping-off the process tank with fresh material is acceptable.

In the original sealed container these products have a shelf life of 18 months when stored below 35°C. Solution viscosity may change over time from the value reported on COA. The rate of change depends upon solvent, % solids and storage conditions. The change in viscosity does not affect polymer performance and the material can be used with no performance loss.

Information on the safe handling of this material is available on the relevant Safety Data Sheet (SDS). Further information is available on request.

Specific local inquiries should be directed to Cymer- Dayton, LLC. To the best of our knowledge this product meets the
definition of a polymer under REACH, and its components are preregistered as substances. The material, or components, is either on the TSCA inventory list or is exempt from the requirement to be listed.
